1000GPD Wholesale Ro Membrane Reverse Osmosis membrane
Reverse Osmosis Membrane technology is a physical separa-tion method Using reverse osmosis membrane to desalt hashigher efficiency and better economic than general ion exchange method and distillation methodWe provide U.s.a Dow membrane and Korean CSM mem-brane which are imported by ourselvesWe also provide Vontron membrane which made in China
Item No :
1000GPDOrder(MOQ) :
1000Payment :
TTProduct Origin :
Jiangsu,ChinaColor :
WhiteShipping Port :
ShanghaiLead Time :
7daysWeight :
5.5kghttps://youtube.com/embed/N9zuZR8_xm8?si=m4B7k_uGU3JY0wzD
1000GPD Wholesale Ro Membrane Reverse Osmosis membrane
Product description:
Reverse Osmosis Membrane technology is a physical separa-tion method Using reverse osmosis membrane to desalt hashigher efficiency and better economic than general ion exchange method and distillation methodWe provide U.s.a Dow membrane and Korean CSM mem-brane which are imported by ourselvesWe also provide Vontron membrane which made in China.
Specfications:
|
Model |
X MEMBRANE-200GPD |
X MEMBRANE-300GPD |
X MEMBRANE-400GPD |
X MEMBRANE-600GPD |
X MEMBRANE-800GPD |
X MEMBRANE-1000GPD |
|
|
Performance |
Stable Desalination % |
97 |
97 |
97 |
97 |
97 |
96 |
|
Min. Desalination % |
95 |
95 |
95 |
95 |
95 |
95 |
|
|
Mean Permeable Flow GPD (L/d) |
200 (760) |
300 (1135) |
400 (1512) |
600 (2270) |
800 (3030) |
1000 (3400) |
|
|
Active Film Area ft2(m2) |
10 (1.0) |
14 (1.4) |
16 (1.92) |
27.5 (2.56) |
34 (3.2) |
36 (3.3) |
|
|
Test Conditions |
Pressure |
65psi (0.45Mpa) |
150psi (1.03Mpa) |
||||
|
Water Temp. |
25℃ |
25℃ |
|||||
|
Concentration(NaCl) |
500ppm |
500ppm |
|||||
|
Water PH |
6.5 to 7.5 |
6.5 to 7.5 |
|||||
|
Recovery Rate % |
15 |
15 |
|||||
|
Operating Conditions |
Max. Operating Pressure |
300psi (2.07Mpa) |
500psi (3.45Mpa) |
||||
|
Max. Feed Water Temp. |
45℃ |
45℃ |
|||||
|
Max. Feed Water Silt Density Index (SDI) |
5 |
5 |
|||||
|
Feed Water Chlorine Tolerance |
< 0.1ppm |
< 0.1ppm |
|||||
|
Feed Water PH Range, Continuous Operation |
3 to 10 |
3 to 10 |
|||||
|
Feed Water PH Range, Short-Term Cleaning |
2 to 12 |
2 to 12 |
|||||
|
Max. Pressure Drop of Single Membrane |
10psi (0.07Mpa) |
10psi (0.07Mpa) |
|||||
product advantages:
Low pressure operation
High water production
Good desalination performance
Good desalination effect on TOC, SiO2, etc.
X MEMBRANE was found in 2014. It is a professional manufacturer which engaged in wastewater industry and supply essential membranes to the engineering companies or the end user.
Address : No. 68-16, Shijiu Lake North Road, Chunxi Town, Gaochun District, Nanjing City, Jiangsu Province, China 210000
